Technical Parameters

• Input Voltage: 230VAC±10%
• Maximum Output Current: 20A (250VAC)
• Adjustable Temperature Range: -19.9℃~99.9℃；Precision：0.1℃
• High/ Low Temp Alarm Output: 2A/230VAC (normally open contact)
• Operating Ambient Temperature: -20℃~85℃

Temperature Sensor

• Cable length: 1.5m
• Specification parameter: NTC R25=10K±1% B25/50=3435±1%

Application

• Working mode: Heating/Cooling
• Modbus Communication: N/A

Technical Parameters

• Input Voltage: 230VAC±10%
• Maximum Output Current: 20A (250VAC)
• Adjustable Temperature Range: -200℃~600℃；Precision：0.1/1℃
• High/ Low Temp Alarm Output: 2A/230VAC (normally open contact)
• Operating Ambient Temperature: -20℃~60℃

Temperature Sensor

• Cable length: 1.5m
• Specification parameter: PT100/PT1000

Application

• Working mode: Heating/Cooling
• Modbus Communication: N/A

Technical Parameters

• Input Voltage: 230VAC±10%
• Maximum Output Current: 20A (250VAC)
• Adjustable Temperature Range: -200℃~600℃；Precision：0.1/1℃
• High/ Low Temp Alarm Output: 2A/230VAC (normally open contact)
• Operating Ambient Temperature: -20℃~60℃

Temperature Sensor

• Cable length: 1.5m
• Specification parameter: PT100/PT1000

Application

• Working mode: Heating
• Modbus Communication: RS485

• Dimensions: 170X120X100mm
• Base Material: Gray ABS
• Top Cover Material: Transparent PC
• Protection: IP67
• Cable Entry Holes
  • 1 x M16 (Cable diameter 4~8 mm) for NTC sensor
  • 1 x M20 (Cable diameter 6~12 mm) for power input cable
  • 1 x M20 (Cable diameter 6~12 mm) for heating cables
  • 1 x M20 (Cable diameter 6~12 mm) for high and low temperature alarm output
